Project X

30-inch Single Row LED Light Bar with RGB

AL538837-1

Performance exactly where you need it. The all-new Series Two LED lights from PROJECT X provide the best output in a range of sizes and feature a f... Read More ►
SPECS:
  • Input Voltage : 9-33V DC
  • LED Type : Cree®
  • Operating Temp : -40°F to 149°F
  • Color Temp : 5700°K
  • Color Rendering Index : 70
  • Raw Lumens : 6,400
Read More ►
Industry Leading Warranty<sup>†</sup> Industry Leading Warranty
Trusted by Professionals<sup>†</sup> Trusted by Professionals
Free Shipping<sup>†</sup> Free Shipping

ABOUT

Performance exactly where you need it. The all-new Series Two LED lights from PROJECT X provide the best output in a range of sizes and feature a full RGB position light. Choose between single or double row LED bars in several lengths up to 30 inches. The Series Two LED bars can be combined in any variation, maximizing light output and versatility where it's needed most.

SPECS

POWER

  • Input voltage : 9-33V DC
  • LED Power : 140W
  • Current Draw @ 13.5V : 7.1A
  • Operating Temp : -40°F to 149°F
  • Heat Management : Active, Thermal Management, System (ATMS)
  • Protection : Reverse Polarity Protection and Under Voltage Protection
  • EMC : ECE R10

LEDs

  • LED Type : 5W Cree® LEDs
  • No. LEDs : 28

LUMENS

  • Color Temp : 5700°K
  • Color Rendering Index : 70
  • Raw Lumens : 6,400
  • Beam Length (1 bar) : 1 lux @ 1640 Feet

CONSTRUCTION

  • Housing : Pressure die-cast aluminum
  • Lens : Hard coated Polycarbonate
  • Hardware : Stainless Steel 304 and 316
  • IP Rating : IP68 & IP69K
  • Weight : 4.5 lbs
