SERIES X 2-HP.85 Bumper Kit for 2021+ Bronco


Easy bolt-on solution for installing two SERIES X HP.85 lights on your 2021+ Bronco modular front bumper using factory accessory ready hardware ... Read More ►

  • Application :
    2021+ Bronco with Modular Bumper
    2021+ Bronco Raptor
    (Does not fit Bronco Sport)
  • Input Voltage : 9-33V
  • Raw Lumens : 43,560
  • Beam Pattern : Combo - Tow HP.85's
  • Mount Material : 304 Stainless Steel
  • Heat Management : Active Thermal Management System (ATMS)
Read More ►
Industry Leading Warranty<sup>†</sup> Industry Leading Warranty
Trusted by Professionals<sup>†</sup> Trusted by Professionals
Free Shipping<sup>†</sup> Free Shipping


Easy bolt-on solution for installing two SERIES X HP.85 lights on your 2021+ Bronco modular front bumper using factory accessory ready hardware and mounting locations.
This kit comes with everything you need to get the optimal performance out of SERIES X HP.85 LED lights totaling 43,560 lumens on the front of your Bronco. The Kit includes two PROJECT X SERIES X HP.85 Lights, two HP.85 Modular Bumper Brackets, and a wiring harness.

Pair and control your new Bumper kit with our the top-rated 12V Switch Panel, Ghost Box by PROJECT X (Sold Separately). Its wiring made simple, allowing you to quickly and easily install and start managing any 12V circuit. Control the Ghost Box via an optional keypad and/or your mobile device. Each circuit offers constant on, strobe, and dimming functions. Quickly cycle through the functions in order from a single button, via the app: turn off any functions you don't need and adjust the strobing and dimming.  Each Ghost Box also features adjustable low voltage protection and over-current protection. Enhance your 12V experience with Ghost Box.


2021+ Ford Bronco 2-door w/ Modular Bumper
2021+ Ford Bronco 4-door w/ Modular Bumper
2022+ Ford Bronco Raptor w/ Modular Bumper
Does not fit Bronco Sport


  • What makes the harness “Ghost Box Ready”?

Cutting and Crimping can be challenging for enthusiasts new to 12v accessories; these can also be the most common failure points when done incorrectly. At PROJECT X we believe in making things “Simple Easy Smart” and so we have designed our wiring harnesses with our Ghost Box system in mind. Each PROJECT X wiring harness includes the 3-pin DT connector to plug into your PROJECT X light and the opposite end is already completed with a ring terminal and the GHOST BOX rubber caps preinstalled, allowing you to plug directly into your ecosystem and sync. It’s that simple, not wire cutting, crimping, soldering etc – we’ve done all the work so you just need a Philips head screw driver to connect it all together!


  • Does 304 Stainless Rust?

You want the best. When you spend your hard-earned money on a premium product the last thing you want to see is the product rusting and looking like a poor reflection of your vehicle, or even worse – failing from deterioration. We take pride in our products as well, so we made all of our mounts out of 304 stainless steel, laser welded so there is no filler, and protected it all with powder-coating. We also include all stainless hardware so your PROJECT X system should look perfect for years to come.


  • Why does a magnet stick to some parts of these stainless 304 mounts?

Note on “magnet testing”: 304 stainless steel contains very low carbon content which is generally the largest contributor to rust, this also makes most areas of the product non-magnetic; however, in areas where cold-work processes have occurred (such as bending) you could see some minor magnetic properties. This is a normal attribute and should not cause any alarm.


  • Will the PROJECT X mounts work on my stock or capable Bronco bumper?

Our PROJECT X Bumpers Mounts are designed to work with the Ford Bronco Modular Bumper which includes all of the accessory ready mounting points and hardware. These mounting points do not exist on the capable bumper or the base model bumper. Additionally, the Raptor uses a slightly modified Modular bumper, with the primary differences being the 1-piece plastic mount cover, the skid plate and the preinstalled fog lights – our mounts have no interference with these items so they will bolt right up!


  • What are the benefits of the Ghost Box vs the factory Bronco upfitter switches?

Why use the Ghost Box instead of the factory upfitter switches? The factory upfitter switches have some great functions but as you start to add more accessories you may find some limitations.

  1. Firstly, the upfitter switches are single function – on/off only. This means you will not be able to set products to dim or flash unless using any additional modules, and you would be locked into that function.
  2. Second, the upfitter switches are only active when the vehicle is powered on, so if you are looking to utilize any accessories while the vehicle is in the ignition-off position.
  3. Third, you are limited to 6 switches. This may be enough for you, but many people find themselves expanding to multiple accessories that will eventually require an additional switching system to control,
  4. Lastly, the maximum circuit size on the upfitter switches is 30amp and there is only a single 30 amp circuit included. That means if you want to run multiple high power lights or accessories you will need to add a relay to each circuit and do additional wiring.

    The Ghost Box system addresses all of the above issues with an expandable ecosystem allowing for dedicated control of all your accessories.
    1. The Ghost Box allows for on-off, flash or dim functions while allowing you to use even when the vehicle is powered off and with the built in multi-level voltage protection you wont need to worry about draining your battery.
    2. Our keypad has 8 buttons ready to be programmed and you are able to merge circuits on the same ghost box to a single button to save space.
    3. The our kit comes with 4 modules (8 total circuits) but is expandable up to 24 modules (48 circuits) to control all of the accessories you could ever want to install.
    4. Each Ghost Box module has adjustable 20 and 40amp circuits, giving you all the necessary power for your accessories. When you don’t need the full ampage you can utilize the PROJECT X app and turn the amps down as low as you need to suit each accessory you connect.


  • Can I merge all the DRL wires to a single circuit?

Our PROJECT  X harnesses are designed to plug and play one set of lights for easy install, which means each DRL will be on a separate button. However, if you want to merge all of your DRLs onto a single circuit that is a great option to consolidate circuits. Each light DRL utilizes roughly 0.1 amps while running, meaning you can run all of them to any ghost box circuit.


  • Do the PROJECT X HP.85 Bumper mounts clear a winch?

If you are running a winch on your Ford Bronco Modular Bumper then our 2 light HP.85 kit will be a perfect addition. Our system utilizes the 4 mounting bolts on each side to secure the lights so they will work without any interference with a Ford Performance winch, or any other standard aftermarket winch system which uses similar mounting.


  • Will the PROJECT X Bumper Mounts block my factory camera?

Our brackets are designed to keep existing vehicle functionality intact. The Bronco Modular Bumper mounts will work perfectly with your front facing trail camera, keeping full functionality. The 4 light HP.70 system will partially block the lower corners of the view, but you will still be able to see the majority of the field of vision. The 2 light HP.85 mounts keep clear vision and do not block any view of the camera, however if used in tandem with the winch, the winch will likely block the view unless the camera is relocated.


  • What are the torque specs for installation?

The Bronco Modular bumper mounts are secured utilizing the factory Bronco bolts. The Ford Torque spec for the M8 bolts are 25+3 N-m or roughly 38 ft lbs.

These utilize a TORX-IP bit, which is different from a standard TORX but. Utilizing a standard TORX can result in the bolt or the tool being damaged.



  • Input Voltage : 9 - 33V
  • LED Power Output : 330W
  • Current Draw @ 12V : 28.8A
  • Power Consumption : 345.6W
  • Operating Temp : -40°F to 149°F
  • Heat Management : Active Thermal Management System (ATMS)
  • Protection : Reverse Polarity, Protection
  • EMC : ECE R10


  • LED Type : Osram LEDs
  • No. LED’s : 33 per Light


  • Color Temp : 5700°K
  • Color Rendering Index : 72
  • Raw Lumens : 43,560
  • Effective Lumens : 30,820
  • Candela : 1,129,624
  • Beam Length (1 lamp) : 1 lux @ 1443 Feet
  • Beam Length (2 lamps) : 1 lux @ 2034 Feet
  • Beam Width (1 lamp) : 1 lux @ 147 Feet
  • Beam Width (2 lamps) : 1 lux @ 206 Feet


  • Mount Material : 304 Stainless Steel
  • Mount Coating : Black Powder Coat
  • Light Housing : Pressure die-cast aluminum
  • Lens : Hard coated Polycarbonate
  • IP Rating : IP66 & IP67
  • Includes : Mount, Two-HP.85, Hardware and Wiring Harness
