TYPE S

TYPE S 10A Battery Charger & Maintainer

AC532575-1

The TYPE S 10A Battery Charger and Maintainer will keep your stored vehicle's battery charged and maintained. Charge standard lead-acid, GEL, AGM, ... Read More ►
Industry Leading Warranty<sup>†</sup> Industry Leading Warranty
Trusted by Professionals<sup>†</sup> Trusted by Professionals
Free Shipping<sup>†</sup> Free Shipping

ABOUT

The TYPE S 10A Battery Charger and Maintainer will keep your stored vehicle's battery charged and maintained. Charge standard lead-acid, GEL, AGM, and lithium-ion (LiFePO4) batteries at 6V or 12V. Easily keep vehicles such as classic cars, trucks, motorcycles, RVs, UTVs, and more charged year-round. Advanced battery recovery mode efficiently repairs and restores impaired battery cells. Battery charger includes SAE connectors.

SPECS

Product Dimensions (charger only):

Length : 6.5 in / 162.5 mm
Width : 3.5 in / 87.5 mm
Height :1.9 in / 47.5 mm



Product Weight:2.7 lb / 1227 g
Input:100-120VAC, 50-60Hz, 165W
Output:12.8VDC 10A Max, 6.4VDC 10A Max
Charging Voltage:6.3VDC, 12.5VDC
Charging Current:10A (6VDC), 10A / 5A (12VDC)
Reverse Current:<5mA
Low Voltage Detection:3.75V (6VDC), 3.75V (12VDC)
Low Voltage Detection: (Push Mode) 0.5V (6VDC), 0.5V (12VDC)
Jump Start Current:400A
Operating Temperature:0ºC ~ 40ºC / 32ºF ~ 104ºF
Storage Temperature:-20ºC ~ 60ºC / -4ºF ~ 140ºF
Battery Types:Standard (Wet Cell /  Flooded, SLA & Maintenance Free)
AGM, GEL, Lithium-ion (incl. LiFePO4)
Fuse:Ring Terminals include 25A Fuse
Connector Type:SAE
Battery Capacity:Up to 300Ah, maintains all battery sizes
IP Rating:IP65; Water-resistant
Model Number:AC532575-1 (UPC 840005325759)
